Unser Tagespreis auf Anfrage unter info@azone.ch oder 043 534 57 25. POWER AMPLIFIER| Number of Powered Channels | 7 | | Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive) | 100 W | | Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive) | - | | Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) | 140 W | | Power Output (6 ohm, 1 kHz, 10% 1ch Drive) | 200 W | | 70% Guarantee | Yes | | Discrete Power Amplifier | Yes | | Amplifier Topology | Class A/B | | Current Feedback Topology | Yes | | Bi-Amp Drive | assignable |
MULTICHANNEL SURROUND TECHNOLOGIES| DTS | DTS HD Master, DTS:X, DTS Neural:X, DTS Virtual:X | | Dolby | Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music, Dolby Surround | | Other | | | Max Number of Processing (Preamp) Channels | 7.2 |
Eingänge/Ausgänge| Composite-Ein-/Ausgänge | 0/0 | | Component Ein- / Ausgang | 0/0 | | HDMI-Ein-/Ausgänge | 6 / 2 | | Multi-Room Video Out via HDMI | 0/0 | | Analog In / Fixed Level Out | 4 in / 0 out | | Phono (MM) Eingang | Yes | | Digital In: Optical / Coaxial | 2 / 2 | | Mehrraum Ausgang: analog / digital | 1 / 0 | | Multichannel Preamp Out | 7.2 | | Subwoofer Ausgang | 2 | | 7.1 Mehrkanal Eingang | No | | Anzahl der Lautsprecher-Terminals | 7 | | Lautsprecher A / B | assignable | | Mehrraum-Lautsprecheranschlüsse | assignable | | Front Inputs | USB-A | | USB Audio | Yes / No / No | | FM Tuner with RDS | Yes | | DAB+ Tuner | Yes |
HDMI| Total HDMI Inputs / No. Support 8K | 6 / 3 | | HDCP2.3 support | Yes | | HDMi-Ausgänge Hauptzone / Zone | 2 / 1 | | Analog to HDMI Video Conversion | No | | HDMI Upscaling | 1080P/4K to 8K | | Max resolution @ framerate | | | Audio-Rückkanal für TV-Ton (ARC) | eARC | | Video Dynamic Range | HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR | | ALLM (Auto Low Latency Mode) Pass-through for gaming | Yes | | Variable Refresh Rate / Quick Frame Transport | Yes / Yes / No | | HDMI Pass-Through im Standby-Modus | Yes | | HDMI-Steuerung (CEC) | Yes | | DSD Audio over HDMI | No | | Auto LipSync | Yes |
PERFORMANCE TECHNOLOGIES| Copper Plated Chassis | No | | Toroidal Power Supply Transformer | No | | Hyper Dynamic Amplifier Modules (HDAM) (List version) | Yes | | Pure Direct Mode | Yes | | Gold Plated RCA Terminals | Yes | | Clock Jitter Reducer | No |
Acoustic / Room Correction| Audyssey | MultEQ XT | | Audyssey Dynamic EQ / Dynamic Volume | Yes / Yes | | Audyssey LFC | No | | Dirac Live Support | No | | Variable Cross Over | Yes | | Optimized Bass Redirection | Yes | | Bass Sync | No |
MUSIC FILE SUPPORT| Lossy Formats | MP3 / WMA / AAC | | Lossless formats | FLAC HD 192/24 / WAV 192/24 / ALAC 192/31 | | DSD Audio | 2.8 MHz / 5.6MHz | | Gapless Playback | FLAC, WAV ,ALAC ,DSD | | Compressed Audio Enhancer: MDAX2 | Yes | | Network Audio Sharing | Yes |
STREAMING SERVICES| HEOS Multi-room and Streaming | Yes | | AirPlay Audio Streaming | AirPlay2 | | Internet Radio | TuneIn | | Spotify* | Spotify Connect | | Pandora | Yes | | SiriusXM | Yes | | Other Streaming Services * | Amazon Music HD/
Amazon Music / TIDAL / Deezer / Napster / Soundcloud / Mood Mix | | Roon tested | Yes |
NETWORK CONNECTIVITY| Ethernet Ports | Yes | | Wi-Fi (include version / band) | Yes | | Bluetooth (Include version) | Yes | | Bluetooth Re-transmit for Bluetooth headphones | Yes |
SMART HOME INTEGRATION AND CONTROL| Voice Assistant Compatibility | Alexa / Google Voice Assistant / Apple HomePod | | App for Smart Phones & Tablets (iOS & Android) | Marantz AVR App | | HEOS Multi-Room Integrated | Yes | | HEOS Link Compatibility: IR/ IP | Yes / Yes | | Multi-Room zones | 2 | | Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog | 2 Ch / 2Ch / Yes / Yes | | Zone Audio Output: Speaker / Preout | Yes / Yes | | Zone HDMI Output from HDMI Source | Yes | | Control Connectivity | IP Control / RS232 Control / Web Control / App Control | | IR Flasher In | Yes | | Marantz Remote Bus | Yes | | DC Trigger Output | 1 | | HDMI Diagnostics | Yes |
Sonstiges| Front Display | port hole OLED | | Primary Display Size (diagonal in/mm) | | | Secondary Display Size (diagonal in/mm) | | | GUI-Sprachen | 9 | | Installations-Assistent | Yes | | Smart Select on Remote | Yes | | Firmware-Update über Netzwerk / USB | Yes / Yes | | ECO Mode | Yes | | Automatische Abschaltung | Yes | | Sleep Timer | Yes |
Allgemeines| Availabe colours | Black/Silver-Gold | | Metallfront | No | | Fernbedienung | RC-049SR | | Stromverbrauch in W | 650 | | Power Consumption No-Sound (ECO on/off) in W | 45 W / 75 W | | Standby-Stromverbrauch in W | 0.2 | | CEC-Standby-Leistungsaufnahme in W | 0.5 | | Network Standby Consumption in W | Less than 2.0 | Maximum Dimensions
Antenna:Horizontal:(W x D x H) in mm
Antenna:Vertical :(W x D x H) in mm
W/o Antenna:(W x D x H) in mm | 442 x 354 x 165
( 442 x 354 x 235 )
【 442 x 343 x 165 】 | | Gewicht in kg | 10.9 | | What's in the box | Main unit, remote control, batteries, AM/FM antennas, wire labels, quick start guide, Audyssey microphone, card board microphone stand, 2 External Detachable Antenna, AC cord |
Unser Tagespreis auf Anfrage unter info@azone.ch oder 043 534 57 25. |
